Slider Top Rack for Gen 1 & Gen 2 KLR 650s

13" x 16" rack

3/16" 6061 aluminum material

Charcoal gray hard anodized

CNC cut

stock tool kit access

hole pattern for Rotopak mount

keyhole mounts for quick connect top box

stainless steel mounting hardware





top box quick connect:



four heavy duty plastic pucks create quiet and tough mounting system

four large 6061 washers

zinc plated button head mounting screws

6061 quick cam lock (top box attaches in less than 10 seconds) when locked into position the box is tightly locked onto the rack

top box can be locked onto rack with a padlock

optional integrated lock is available

mounting is symmetrical, box can be mounted in one orientation and 10 seconds later be mounted in a different orientation

top box can be attached and removed without opening the box

rack & top mount kit is $149.90
or
rack only can be purchased for $99.95 and mount kit $49.95
free shipping to inmates in the CON USA

Our website is under construction, so PM me if you would like to buy one and get the ADVrider free shipping deal.

Rack for Gen 1 or Gen 2 KLR 650

[/URL]

Top box quick connect kit

[/URL]

Gen 2 KLR 650 with rear top rack
[/URL]

Image of Kawasaki KLR 650 rear rack
[/URL]

Rear view of Gen 2 KLR 650 with Pelican case mounted as a top box

[/URL]

Dry bag mounted with flat straps or hooked strap on top rack

[/URL]

Rotopax container mounted on top rear rack

[/URL]

Pad lock in place to lock top box to rack by locking attachment lever

[/URL]



Steve
