Any TE450 or TE510 owners here?

[bodhizafa]

Originally Posted by AustinJake

After finding what I found yesterday, I would suggest you check your Green/red stripe wire first thing. It was the source of my cutting out, blubbering, back-firing and sometimes dying. Incredibly, this wire is connected to the fuel pump, the fuel pump relay, the fuel injector and the coil!

Where's that green sucker located? Under the tank I'm guessing. My FI seems to start up, I can hear something when the key is turned. I need to figure out if its squirting gas. Getting annoyed with all the little problems with this bike.

[AustinJake]

Originally Posted by poppy

Was wondering if anyone stateside might be able to give me a leed on who i could contact to have a new clutch slave sent out for my 05 TE 510.

Originally Posted by Ruffus

It's on their web page, just go to engine accessories.
http://www.ziptyracing.com/engine-accessories/

I never can find that! Thanks man, that should fix poppy up.

http://www.ziptyracing.com/husqvarna...h-slave-cover/

[poppy]

Many thanks AustinJake & Ruffus, much appreciated & lesson learnt. I thought i had the bleed valve loose as i was twisting it with my fingers, but must have tweaked it a bit tight. Expensive lasp in concentration.



Thanks again.

[Ruffus]

Originally Posted by poppy

Many thanks AustinJake & Ruffus, much appreciated & lesson learnt. I thought i had the bleed valve loose as i was twisting it with my fingers, but must have tweaked it a bit tight. Expensive lasp in concentration.



Thanks again.

Have you posted this on Cafe Husky? There may be a dealer that carries ZipTy products & can send it you, or a brand new factory unit. If I recall correctly, they were fairly close in price.
Must be getting old here, I can't even remember who I ordered it through. I think it was Hall's.
You could try Bill's on the west coast, Motoxotica in the south west. or Hall's in the east.

[Bonerov]

This is my first post in this thread, but I've read just about every single post here. I am borrowing an '04 TE450 and have really only ridden it once. That said, it's a fantastic machine. There was a bit of a carb issue (slide sticking, due to a bushing issue), but I sorted it out. I FINALLY got the chance to ride it this weekend, and was VERY impressed. SO much low end grunt. Silky smooth suspension. Love it! My buddy loaned me this bike with the hopes that I would buy it, and it looks like his gamble will pay off.

[Ruffus]

Originally Posted by Bonerov

This is my first post in this thread, but I've read just about every single post here. I am borrowing an '04 TE450 and have really only ridden it once. That said, it's a fantastic machine. There was a bit of a carb issue (slide sticking, due to a bushing issue), but I sorted it out. I FINALLY got the chance to ride it this weekend, and was VERY impressed. SO much low end grunt. Silky smooth suspension. Love it! My buddy loaned me this bike with the hopes that I would buy it, and it looks like his gamble will pay off.

Keep an eye on the valves, can't remember if it was 04, or 05 that had a bad batch of valves & stainless were usually put in to remedy the it. If it's already got the stainless, you're golden.

[tntmo]

I've been suffering the summer through with my TE450 in supermoto trim. Next week is desert season, so the smooth shoes will come off and the knobbies go back on. Here's a pic from the last supermoto ride of the year today.


IMAG0195 by tntmo2, on Flickr

[poppy]

Originally Posted by Ruffus

Have you posted this on Cafe Husky? There may be a dealer that carries ZipTy products & can send it you, or a brand new factory unit. If I recall correctly, they were fairly close in price.
Must be getting old here, I can't even remember who I ordered it through. I think it was Hall's.
You could try Bill's on the west coast, Motoxotica in the south west. or Hall's in the east.

Nah mate, have not posted on cafe husky. I have bought through halls before actually, thanks for the reminder, i will give them a try as well. Thanks again, you guy's have been most helpful.

[poppy]

Originally Posted by Ruffus

Keep an eye on the valves, can't remember if it was 04, or 05 that had a bad batch of valves & stainless were usually put in to remedy the it. If it's already got the stainless, you're golden.

It is the 04 with the crappy valves, they changed to Del West valves for the 05 models. I have had my 05 since new and valves are right where they were set after the 1st valve check. have both inlet and exhaust at .008 or .2032mm .

[bodhizafa]

Originally Posted by tntmo

I've been suffering the summer through with my TE450 in supermoto trim. Next week is desert season, so the smooth shoes will come off and the knobbies go back on. Here's a pic from the last supermoto ride of the year today.


IMAG0195 by tntmo2, on Flickr

Suffering......ya the horror!

[Bonerov]

Thanks for the info about the valves on the '04. I'll see if my buddy knows what kind of valves are in this one. He bought it recently from someone on CL, so he may not know for sure. This guy buys and sells bikes like a madman. I can't complain, since it has benefited me a few times :)

[mootsuno]

Originally Posted by poppy

Was wondering if anyone stateside might be able to give me a leed on who i could contact to have a new clutch slave sent out for my 05 TE 510. Went to change the o-ring and bleed it up while i had it unbolted to the bike and the circlip shot off. I checked prior to doing anything that it was seated properly,which it was. Maybe there was an issue with the casting, not sure, but now i need a new one. So instead of just costing me 40 cents for a new o-ring, it now looks like it will cost a small fortune to buy the whole slave here. I actually just need a housing, but dont like my chances of just find that. You cant just by o-rings here from husky dealers either, you have to buy the complete kit. I think 05,6,7, 250, 450, 510 are all the same, not sure of the ealier/later models.

Thanks for any help.

Here is a pic of the circlip retaining edge.

I had the same problem. Ordered the part from Motoxotica. They had it in stock.

http://www.motoxotica.com

[AustinJake]

Had a problem with the TE 450 dying and not running right after some deep water crossings, 10-15 minutes later, bike was fine. I suspected the TPS for a while until I looked at the Gear Position Sensor (GPS) down under the clutch slave. Got the GPS pulled, was lucky the spring didn't come out with the bullet pin, and I found worn insulation with exposed wire, most likely letting water all the way into the system, thus grounding it out or at least, interrupting or distorting the correct resistance values for each gear. I used some hi-temp silicone, and plenty of it, plus layered on some more when I had it installed since the wire had to be flexed back and forth to get the unit back in, I didn't want any openings to expose the repair. Looking at the location of the GPS and knowing that alot of chain lube ends up there, I am now thinking that the water that flooded the GPS came from the chain, deep puddles that the rear wheel HAS to go thru, even when you lift the front wheel over the water, the chain is bringing water up and then down on top of the GPS.




The bullet pin goes into the shift drum in the bike, and then you can see the 6 gear positions on the GPS with the little neutral spot in between 1st and 2nd gear.

[mattomoto]

Originally Posted by AustinJake

Had a problem with the TE 450 dying and not running right after some deep water crossings, 10-15 minutes later, bike was fine. I suspected the TPS for a while until I looked at the Gear Position Sensor (GPS) down under the clutch slave. Got the GPS pulled, was lucky the spring didn't come out with the bullet pin, and I found worn insulation with exposed wire, most likely letting water all the way into the system, thus grounding it out or at least, interrupting or distorting the correct resistance values for each gear. I used some hi-temp silicone, and plenty of it, plus layered on some more when I had it installed since the wire had to be flexed back and forth to get the unit back in, I didn't want any openings to expose the repair. Looking at the location of the GPS and knowing that alot of chain lube ends up there, I am now thinking that the water that flooded the GPS came from the chain, deep puddles that the rear wheel HAS to go thru, even when you lift the front wheel over the water, the chain is bringing water up and then down on top of the GPS.

The bullet pin goes into the shift drum in the bike, and then you can see the 6 gear positions on the GPS with the little neutral spot in between 1st and 2nd gear.

Man, good observation there Jake. Will be checking mine. I have had that a few times after water crossings/small stream. Might be the answer to mine also... I have sealed the coil and all the other stuff I can but that looks like a good spot for leaks too. Thanks.

Matto

[AustinJake]

Originally Posted by mattomoto

Man, good observation there Jake. Will be checking mine. I have had that a few times after water crossings/small stream. Might be the answer to mine also... I have sealed the coil and all the other stuff I can but that looks like a good spot for leaks too. Thanks.

Matto

It definitely cured my problem, got in some deep water today, not one hiccup, ran like a beast on an urban dual sport ride.
